Products
aerto pro
The aerto pro delivers maximum application quality, even with the most difficult adhesives.
Get Offer
Overview Technical Information
Overview Technical Specifications
Overview

Electropneumatic head for bead and dot application

The aerto pro delivers maximum application quality, even with the most difficult adhesives. The powerful long-life module with innovative sealing technology convinces with perfect application at all speeds.

- Maximum flexibility in adhesive selection

- Long service life

- Perfect dot application

- Low maintenance costs

Technical Specifications

Technical data

SpecificationValueUnit
Temperature range0-200°C
Temperature monitoringPt 100
Switching frequency*350**/280 or
21.000**/16.000

Hz
cycles/min.

Connection15 pole plug
Hose connection1/2“ UNF
Adhesive pressure80bar
Adhesive viscositymax. 60.000mPa.s
Noise emission82dB***

* depending on nozzle size, adhesive and pressure**

no continuous operation*** with sound insulation
