DPP-8
DPP-8 double piston pump is your greatest assistant in situations where high pressure and ideal pressure control are required. It helps during failure and production thanks to its own display.
Get Offer
Overview

Adhesive conveying in perfection

DPP-8 double piston pump
The precise electronic control of the two pistons enables the ideal pressure control of the adhesive at any production speed. A material pressure regulator is therefore not required and the adhesive is thus protected.

- High-pressure pump for maximum production speeds

- Networking with Xtend³ control unit

- Intelligent communication

- Error messages in the display

Technical Specifications

Technical Data

SpecificationValueUnit
Regulated output pressure max.40bar
Air inlet pressure6-7bar
Pressure ratio8:1
Adhesive viscosity6.000mPaS
Max. delivery rate2L/min
Connected load12W
Weight20,5kg
