HP-500
With its integrated pneumatic valve, the HP-500 impresses with its compact design.
Get Offer
Overview Technical Information
Overview Technical Specifications
Overview

The compact application head

With its integrated pneumatic valve, the HP-500 impresses with its compact design. It can be integrated into the tightest installation spaces and is ideally suited for integration into robotic applications, among others.

- Small installation space

- Great flexibility in the choice of adhesive

- Wide range of applications

- Extremely quiet

Technical Specifications

Technical data

SpecificationValueUnit
Temperature range0-200°C
Temperature monitoringPt 100
Switching frequency*150Hz
Connection9-pole AMP-Plugr
Hose connection1/2"  UNF
Adhesive pressure80bar
Noise emission70dB
*Depending on nozzle size, adhesive and pressure
