Robust and precise
Electronically controlled piston pump for maximum demands.
Conveying unit for medium to high viscosity materials.
- Minimal maintenance
- Uniform adhesive application
- FDA approval
Overview
Electronically controlled piston pump for maximum demands.
Conveying unit for medium to high viscosity materials.
- Minimal maintenance
- Uniform adhesive application
- FDA approval
Technical Data
| Specification | Value | Unit |
|---|---|---|
| Regulated output pressure max. | 35 | bar |
| Theoretically max. achievable outlet pressure at 6 bar air inlet pressure | 54 | bar |
| Compressed air connection | 6-8 | bar |
| Pressure ratio | 9:1 | |
| Adhesive viscosity | 10.000 | mPaS |
| Max. delivery rate | 2,5 | L/min |
| Connected load | 12 | W |
| Weight | 32 | kg |
