Proven thousands of times
Users rely on the P-500's precision and performance.
- Robust construction
- Long service life
- Switching cycles up to 500 Hz
- Reduced adhesive consumption due to dot application
- Multiple heads available
Overview
Users rely on the P-500's precision and performance.
- Robust construction
- Long service life
- Switching cycles up to 500 Hz
- Reduced adhesive consumption due to dot application
- Multiple heads available
Technical Data
| Specification | Value | Unit |
|---|---|---|
| Operating pressure | 1,0 - 50,0 | bar |
| Adhesive viscosity | 3.000 | mPaS |
| Possible nozzle diameters | 0.3, 0.4, 0.5, 0.6, 0.8, 1.0 | mm |
| Temperature range | 15 - 45 | °C |
| Relative humidity max. | 70 | % |
| Noise emission | <70 | dBa |
| Switching frequency | 500 | Hz |
| File Name | File Size | File Type |
|---|---|---|
| Click to download P-5000 Cold Glue Application Head Brochure | 255,04 KB |
