PX 1000
The PX 1000 is the most powerful cold glue valve available.
Get Offer
Overview

PX 1000 The new standard in cold glue application

The PX 1000 is the most powerful cold glue valve available.

With its great power, the PX 1000 ensures the operator greater flexibility in the choice of adhesives and ensures perfect bonds from the first product.

- High closing force

- Perfect start-up behaviour

- Switching cycles up to 750 Hz

- Tailing-free application

- Adhesive saving through dot application

- Multiple heads available

Technical Specifications

Technical Data

SpecificationValueUnit
Operating pressure1,0 - 50,0bar
Adhesive viscosity4500mPaS
Possible nozzle diameters0.3, 0.4, 0.6mm
Temperature range15 - 45°C
Relative humidity max.70%
Noise emission<70dBa
Switching frequency750*Hz

*at 20bar adhesive pressure and 1.000 mPaS



Downloads
File NameFile SizeFile Type
Click to download PX 1000 Cold Glue Application Head Brochure 624,90 KBPDF
