Products
V-500
This extremely small and fast dot application head was developed for use in tight spaces.
Get Offer
Overview Technical Information
Overview Technical Specifications
Overview

For fast dot application

It is specially designed for the small installation spaces in OEM machines and impresses with its high-frequency dot application with low-viscosity adhesives.

- Switching cycles up to 1000 Hz

- Dot application

- Only 15 mm module width

Technical Specifications

Technical Data

SpecificationValueUnit
Operating pressure1,0 - 6,0bar
Adhesive viscosity1.000mPaS
Possible nozzle diameters0.3, 0.4, 0.5mm
Temperature range15 - 45°C
Relative humidity max.70%
Noise emission<70dBa
Switching frequency1.000Hz
