Products
XBM
The Xmelt PUR bag melters are user-friendly and easy to clean.
Get Offer
Overview Technical Information
Overview Technical Specifications
Overview

Efficient PUR bag melter

The Xmelt PUR bag melters are user-friendly and easy to clean. The adhesive is gently melted to prevent viscosity changes and to ensure consistent production conditions.

- Melt on Demand

- Easy cleaning

- No inert gas filling necessary

- Capacitive level measurement

- Bag diameter Ø150 mm and Ø 132 mm

Technical Specifications

Technical data

SpecificationValueUnit
Temperature range20-160°C
Level monitoringCapacitive sensors
Tank capacity2l for 2 kg bag
Tank diameter130 or 150mm
Melting capacity4kg/h
Hose connections

2 or 4


Noise emission<70dB
Maximum viscosity30.000Pa*s
Maximum adhesive pressure70bar
