Products
Xfeed center
With the Xfeed center, you always have an overview of your production.
Get Offer
Overview Technical Information
Overview Technical Specifications
Overview

Adhesive distribution to all connected lines according to demand.

With the Xfeed center, you always have an overview of your production. All requirements converge here. The centre distributes the adhesive to all connected lines. Demand-driven and reliable.

The heart of adhesive supply.

- Production always in view

- Dosing tower for delivery volumes from 0.5 l to 10 l

- Automated distribution

Technical Specifications

Technical data

SpecificationValueUnit
Power consumption182W
Weight85kg
Delivery volume0,5 , 1 , 2l
Ambient temperature5-40*C°
Degree of protection54IP
Delivery hose connectionØ-Innen 25
Ø-Außen 32		mm
Air hose connectionØ-Innen 19
Ø-Außen 27		mm
Compressed air2,3-2,7bar
Noise emission62,5**dB
Granulate size2-8 +/- 20%mm

*Depending on adhesive, **DIN EN ISO 9614-1
