Adhesive distribution
The distributor distributes the adhesive to the connected lines. With its 8 outputs, 8 hot-melt gluers can be connected. If further lines are to be integrated, the system can be expanded.
The distributor distributes the adhesive to the connected lines. With its 8 outputs, 8 hot-melt gluers can be connected. If further lines are to be integrated, the system can be expanded.
Technical data
Specification | Value | Unit |
---|---|---|
Power consumption | 264 | W |
Weight | 27 | kg |
Ambient temperature | 5-40* | C° |
Degree of protection | 54 | IP |
Delivery hose connection | Ø-Innen 25 Ø-Außen 32 | mm |
Hose connections | 8 | |
Noise emission | 67,3** | dB |
Granulate size | 2-8 +/- 20% | mm |
* Adhesive dependent **DIN EN ISO 9614-1
