XM-12
User-friendly melter for high volume requirements
Get Offer
Overview

Saves energy and protects the adhesive

The Xmelt melters have been developed for a wide range of applications in various industries. The efficient units are characterised by low energy consumption and thus help to minimise the CO2 emissions of your production.

  • Two zone tank
  • Double acting, electronically controlled piston pump *
  • Up to 8 hose connections
  • Temperature control with PID
  • Industrial communication connection
  • Capacitive level monitoring
  • Automatic ECO Mode
  • Double filtration on suction side
  • Capacitive glue level sensor
Technical Specifications

Technical Data

SpecificationValueUnit
Temperature range20-200°C
Control accuracy± 0,5°C
Degree of protectionIP40
Noise level<70dB
Heating time19min
Heating capacity tank, 3/N/PE AC2,9kW
Heating capacity tank, 3/PE AC2,2kW
Rated current tank, 3/N/PE AC6,61A
Rated current tank, 3/PE AC5,75A
Tank capacity12kg
Melt capcity11,2kg/h
