XM-4
This 4-liter Xmelt melter is just what you need with its compact structure.
Get Offer
Overview

Saves energy and protects the adhesive

The Xmelt melters have been developed for a variety of applications in different industries. The efficient units feature low energy consumption, helping to minimise the CO2 emissions of your production.

  • Two zone tank
  • Double acting, electronically controlled piston pump *
  • Up to 6 hose connections
  • Temperature control with PID
  • Industrial communication connection
  • Capacitive level monitoring
  • Automatic ECO Mode
  • Double filtration on suction side
  • Capacitive glue level sensor



* Also available with gear pump.

Technical Specifications

Technical Data

SpecificationValueUnit
Temperature range20-200°C
Control accuracy± 0,5°C
Degree of protectionIP40
Noise level<70dB
Heating time20min
Heating capacity tank, 3/N/PE AC2,1kW
Heating capacity tank, 3/PE AC1,46kW
Rated current tank, 3/N/PE AC4,59A
Rated current tank, 3/PE AC3,83A
Tank capacity4kg
Melt capacity8kg/h
